Motor Focus Kit v2 (Universal)

Focus accurate and fast your telescope using our powerful Motor Focus Kit. This high resolution geared box has a 0,06 degree step size can can easily lift more than 6 Kg (per cm). Its high torque is suitable for lifting heavy imaging equipment. Moreover motor’s gearbox has a low backlash which can easily tuned using backlash compensation in imaging software.

An L-shaped black anodised aluminium bracket, hard to bend, has cut rails and can be attached to a wide range of focusers.

Inside the box:

• High Resolution Stepper Geared Motor Enclosure (Step Angle 7.5, Deg 120, Gear Ration 1:120). Its gearbox has very low backlash and high torque suitable to focus in micron scale.
• Universal Black Anodised Aluminium L shaped bracket for Motor
• Motor Coupler (5mm to 10mm) with 3 grub-screws
• Different sizes of bolts and spacers

Note: You will need a stepper controller to drive the motor. We recommend PegasusAstro Kontroler do motofokusera DMFC. Alternatively, you can control this motor with the PegasusAstro Ultimate Powerbox v2 Hub (additional RJ45 to RJ45 cable required).
